Change color of PdfPathContent

I need to loop through the elements of a existing (base) PDF (it’s a certificate) and change the Fill color of certain PDF Path elements but I also notice that paths can be in a PdfGroupContent element as well.

Q1: What is the best way to find all ‘Paths’ in the document or do I just need to write code to loop through all document elements to find them?

Q2: The best way I can think of indicating which ‘Paths’ need to have their color changed, is to set them to a unusual color in the base PDF, then if the element has that color, change it. Am I missing a simpler way to achieve this solution?

Hi Simon,

A1: Try this:

using var document = PdfDocument.Load("input.pdf");
var page = document.Pages[0];

foreach (var pathElement in page.Content.Elements.All(true).OfType<PdfPathContent>())
{
    // ...
}

A2: Are the targeted path elements in a specific area?
If you are, you could try using this:

using var document = PdfDocument.Load(desktop + "\\input.pdf");
var page = document.Pages[0];

double areaLeft = 100,
    areaRight = 200,
    areaBottom = 300,
    areaTop = 400;

var contentEnumerator = page.Content.Elements.All(page.Transform, true).GetEnumerator();
while (contentEnumerator.MoveNext())
{
    if (contentEnumerator.Current.ElementType != PdfContentElementType.Path)
        continue;

    var pathElement = (PdfPathContent)contentEnumerator.Current;
    var bounds = pathElement.Bounds;
    contentEnumerator.Transform.Transform(ref bounds);

    if (bounds.Left > areaLeft && bounds.Right < areaRight && bounds.Bottom > areaBottom && bounds.Top < areaTop)
    {
        // ...
    }
}

Regards,
Mario

Hi Mario,

Either the code given in A1 is not working or when I change the color of the elements within the group the new color is not being applied.

Original:

After code is run to change Green to Blue:

Dim borderColour As GemBox.Pdf.Content.PdfColor = GemBox.Pdf.Content.PdfColor.FromRgb(borderR1 / 255, borderG1 / 255, borderB1 / 255)

Dim contentEnumerator = page1.Content.Elements.All(page1.Transform).GetEnumerator()
While contentEnumerator.MoveNext()
    Select contentEnumerator.Current.ElementType
        Case GemBox.Pdf.Content.PdfContentElementType.Path
            process_gemboxPath(contentEnumerator.Current, borderColour)
        Case GemBox.Pdf.Content.PdfContentElementType.Group
            process_gemboxGroup(contentEnumerator.Current, borderColour)
    End Select
End While

Private Sub process_gemboxGroup(ByRef g1 As GemBox.Pdf.Content.PdfContentGroup, borderColour As GemBox.Pdf.Content.PdfColor)
    For Each e3 In g1.Elements
        Select Case e3.ElementType
            Case GemBox.Pdf.Content.PdfContentElementType.Path
                process_gemboxPath(e3, borderColour)
            Case GemBox.Pdf.Content.PdfContentElementType.Group
                process_gemboxGroup(e3, borderColour)
        End Select
    Next
End Sub

Private Sub process_gemboxPath(ByRef p1 As GemBox.Pdf.Content.PdfPathContent, borderColour As GemBox.Pdf.Content.PdfColor)
    p1.Format.Fill.Color = borderColour
End Sub

Please send us a small Visual Studio project together with your input PDF file that reproduces the issue so we can investigate it.

Regards,
Mario

My apologies Mario,

While creating your last request, I realized that I had to change the color of both Fill and Stroke to get all objects to be of the same color. Obvious when I think about it now!

Anyway, thank you for your help and code to my original question.

Regards,

Simon.
